ASME SEC VIII DIV 1 DESIGN & CONSTRUCTION (PD442)

The ASME Approved Pressure Vessel Design Course (23 PDH) provides a complete foundation in ASME Sec VIII Div-1. Covering internal & external pressure design, nozzles, flanges, materials, welds, supports, and combined loading, this training ensures engineers will be aware of the design & optimization of pressure vessels and various ASME SEC VIII DIV 1 clauses Also, you will have access to the ASME Sec VIII Div 1 code book during the live training sessions on ASMEs digital platform and a 4-month membership.

instructor: Sachin Pol

Duration: 23 Hours

Detailed 3D CAD model of a vertical pressure vessel with multiple nozzles for ASME Section VIII Division 1 design training

SERVICES

11 lectures
23h Duration

Are you tasked with the design or fabrication of pressure vessels, but are not sure where to begin with code requirements?
This course is a comprehensive introduction to the requirements of the current Edition of the ASME Boiler and Pressure Vessel Code (B&PVC), Section VIII, Division 1
Beginning with a unique insight into the background and organization of the code, the course focuses on design and construction requirements
Participants will explore requirements related to materials, fabrication, inspection, testing, and certification of pressure vessels
The course highlights commonly applied subsections, paragraphs, and appendices
This course focuses on design, fabrication, and certification of pressure vessels with respect to BPVC VIII-1
Participants will perform example calculations on Appendix 2 flanges, nozzle reinforcement, and more
Real-world case studies include Opening Reinforcements / Nozzle Reinforcement and Appendix 2 Bolted Flange Calculation

Describe scope, purpose, and organization of the Code
Define allowable materials and explain material reclassification and traceability requirements
Apply Code rules to common design and fabrication situations
Identify calculations for loadings and situations not addressed by the Code
Describe preparation of design specifications, design reports, data reports, and documentation

Introduction to ASME Codes and Section VIII
General Design Requirements
Design for Cylindrical Shells, Dished Heads, Flat Heads, Covers & Openings (Internal & External Pressure)
Fabrication, Testing, Welding & Examination
Requirements for Steels & Heat-Treated Materials
